Rapid Fire Extinguishing Without Set-Up Time!
OERTZEN HP Fire Extinguishing Unit without tank - installation version
extinguishing pressure 250 bar
water flow rate 23 l/min
DUPLEX rapid attack attachment for spray and low expansion foam
60 m high pressure extinguishing hose
olid, surrounding steel frame (powder coated) with 4 rubber/metal bumpers, 2 cyl./ 4 stroke petrol engine (heavy duty) 13.2 kW/18 hp, with oil pressure control, electric and recoil rope starter, petrol tank 5 l (canister), reduction gearbox (pump rpm 1450 1/min), 3 cyl. inline plunger pump 23 l/min (splash oil lubricated) forged crankshaft, wear-free ceramic plungers, forged brass cylinder head, stainless steel valves, foam agent injection (3 %) with stop valve, thermo valve (prevents overheating), pressure relief for pump by hp unloader valve with extinguishing pistol closed
Standard equipment: DUPLEX rapid attack attachment for spray and low expansion foam, 60 m PANZERJET hp extinguishing hose (500 bar) on hose reel with swivel joint, crank and brake, hose swivel, lockable extinguishing pistol
| Technical characteristics | |
|---|---|
Dimensions (frame) | 980 x 560 x 560 mm |
Weight | 138 kg (without tank) |
Engine/motor | 4-stroke petrol engine, 2 cyl. 13.2 kW |
Start | electric / recoil rope starter |
HP plunger pump | 3 cyl. 23 l/min |
Extinguishing pressure max. | 250 bar |
HP hose | 60 m (500 bar) |
Water tank | - |
Foam agent injection | standard |
Extinguishing pistol | DUPLEX Attachment |
